Stackable 51.2V 102AH 5000W Battery Pack for Home Energy Storage System Low Voltage & High Power
Stackable 51.2V 102AH LiFePO4 battery pack delivers 5000W output for home energy storage. Scalable to 15KWh with parallel connection. Features smart BMS protection, solar/grid compatibility, 6000+ cycles. Low-voltage & plug-and-play design for safe renewable energy storage.
- Overview
- Recommended Products
Products Description
Specifications |
Parameters |
||||
Product composition |
Inverter+PACK+Base |
||||
Battery module specifications |
51.2V102AH |
||||
IP rating |
IP21 |
||||
Number of battery modules |
1 |
2 |
3 |
||
Total battery capacity (KWH) |
5.12 |
10.24 |
15.36 |
||
Dimensions
(W * H * D)/mm
|
600*655*163 |
600*1005*163 |
600*1355*163 |
||
Weight/KG |
60.8 |
108 |
155.2 |
||
Communication method |
CAN/485 |
||||
MPPT voltage range/VDC |
150-500V |
Input voltage/AC |
90~280V(Household Electric Appliances) 170~280V(computer equipment) |
||
output voltage |
208/220/230/240VAC |
Maximum photovoltaic power |
5000W |
||
output power |
5000W |
Number of cycles |
4000~6000 |
||
Maximum discharge current/DC |
100A |
||||
application |
Grid connected/off grid |
||||
Wiring method |
individual |
||||
Friendly operation,expandable battery capacity:
- Supports connection of up to 15 units.
- Maximum continuous charge/discharge current: 1500A.
- Maximum available battery capacity: 76.8kWh.
- Maximum inverter load power: 33kW.
- Cycle life: Over 6000 cycles.
- Supports connection of up to 15 units.
- Maximum continuous charge/discharge current: 1500A.
- Maximum available battery capacity: 76.8kWh.
- Maximum inverter load power: 33kW.
- Cycle life: Over 6000 cycles.
Company Profile
FAQ
FAQ
If you have any questions, feel free to contact us.
Q:Do you have MOQ ?
Q: What kind of company are you?
A: Our company was established in 2022 and is a high-tech enterprise specializing in the research and development, production, sales, and service of energy storage equipment. We are committed to providing global customers with energy storage products that are high in efficiency, reliability, and longevity, meeting the energy storage needs of various scenarios.
Q: What are the main businesses of your company?
A: Our business covers the research and development, production, and sales of energy storage equipment, as well as after-sales services. Our products are widely used in residential energy storage, commercial energy storage, industrial energy storage, and renewable energy storage, offering customized energy storage solutions to customers.
Q. Can I print LOGO on it?
A: YES, LOGO/sticker/OEM/ODM welcomed
Q. What services can provide?
A:Accepted DeliveryTerms: DDP,Express Delivery;
Accepted Payment Currency:USD,EUR,CAD;
Accepted Payment Type: T/T,D/P D/A,Credit Card,PayPal,Cash;
Q:Do you have MOQ ?
A:No limited. Small order also welcome.More quantity has better price, we will check the best price for you.
